The 400 V electric chain hoists are extremely solid and have a robust sheet steel housing. Very popular as it is ready to use with limit switches, 24 V control voltage, controlunit and plug connections. The high duty cycle and high lifting speed ensure trouble-free operation and a long service life.

Properties

  • Slip clutch against overload.
  • Brake that holds the load at any desired height.
  • Limit switches for highest and lowest hook positions.
  • Operation 24 Volt control voltage.
  • Power and control cables are equipped with plug connection.
  • Phase protection against incorrect rotation of the motor.
  • Galvanized load chain, Class DAT (Grade 8).
  • Operating voltage 400 VAC / 50 Hz.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • 1 speed.

Standard delivery

  • 3 m lifting height (maximum distance between top and bottom hook).
  • 1.8 m control cable.
  • Limit switches highest and lowest hook position.
  • Push-button 24 V control unit.
  • 4 m power cable.
  • Plastic chain bucket for 3 m lifting height.
  • Trolley not included.

Option

  • Increased lifting and/or control height.
  • Larger chain bucket > 3 m lifting height.
  • Radio remote control.
  • Push / electric trolley.
  • 440 V / 60 Hz on request
  • Marking: According to standard, CE-marked
  • Standard: EN 818-7, EN 12100, EN 14492
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Lifting height
m
Model Operation voltage (V) Motor power
kW
Max. lifting height
m
Load Chain dia x pitch
mm
Protection Chain falls Lifting speed
m/min.
Duty rating % ED Duty group of hoist FEM 9.511 Construction height
mm
A
mm
B
mm
C
mm
D
mm
H
mm
K
mm
L
mm
M
mm
N
mm
O
mm
Isolation class Weight
kg
0515001-3 8717365085284 0,5 3 FAH/500KG/3M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 43
0515001-4 8717365085291 0,5 4 FAH/500KG/4M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 45
0515001-5 8717365085307 0,5 5 FAH/500KG/5M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 47
0515001-6 8717365085314 0,5 6 FAH/500KG/6M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 49
0515001-7 8717365085321 0,5 7 FAH/500KG/7M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 51
0515001-8 8717365085338 0,5 8 FAH/500KG/8M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 53
0515001-9 8717365085345 0,5 9 FAH/500KG/9M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 55
0515001-10 8717365085352 0,5 10 FAH/500KG/10M 400 0,9 30 6.3 x 19.1 IP54 1 7 40 1Am 480 161 124 224 311 480 36 26 86 24 19 E 57
0515003-3 8717365085369 1 3 FAH/1000KG/3M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 58
0515003-4 8717365085376 1 4 FAH/1000KG/4M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 60
0515003-5 8717365085383 1 5 FAH/1000KG/5M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 62
0515003-6 8717365085390 1 6 FAH/1000KG/6M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 63
0515003-7 8717365085406 1 7 FAH/1000KG/7M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 64
0515003-8 8717365085413 1 8 FAH/1000KG/8M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 66
0515003-9 8717365085420 1 9 FAH/1000KG/9M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 68
0515003-10 8717365085437 1 10 FAH/1000KG/10M 400 1,6 30 7.1 x 21.2 IP54 1 7,6 40 1Am 570 170 128 239 348 570 43 33 107 31 23 E 70
0515005-3 8717365085444 2 3 FAH/2000KG/3M 400 1,6 15 7.1 x 21.2 IP54 2 3,8 40 1Am 710 133 165 239 372 710 53 42 144 44 30 E 64
0515005-6 8717365085475 2 6 FAH/2000KG/6M 400 1,6 15 7.1 x 21.2 IP54 2 3,8 40 1Am 710 133 165 239 372 710 53 42 144 44 30 E 73
0515005-10 8717365085512 2 10 FAH/2000KG/10M 400 1,6 15 7.1 x 21.2 IP54 2 3,8 40 1Am 710 133 165 239 372 710 53 42 144 44 30 E 85
0515007-3 8717365085529 3 3 FAH/3000KG/3M 400 1,6 10 7.1 x 21.2 IP54 3 2,5 40 1Am 810 148 208 239 427 810 60 50 165 49 35 E 78
0515007-6 8717365085550 3 6 FAH/3000KG/6M 400 1,6 10 7.1 x 21.2 IP54 3 2,5 40 1Am 810 148 208 239 427 810 60 50 165 49 35 E 90
