The REMA Beta 230 VAC electric chain hoists are light weight, compact and ideal for light installation work.

Properties

  • Slip clutch for overload prevention
  • Self-locking brake that will hold the load at any required height
  • Very low own weight, only 7.5 kg.
  • Very compact.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • Grade 10 load chain.

Technical specification:

  • Insulation class B.
  • FEM 9.511 motor: 1Am.
  • Power supply 230VAC.
  • Protection class IP54
  • Control power supply 230VAC direct control.

Standard delivery

  • 3 m lifting height (maximum distance between top and bottom hook).
  • 1.8 m control cable, direct control.
  • 3 m power cable.
  • Chain bag max 10 m.
  • Trolley not included.

Option

  • Other hoisting and operating height is also possible.
  • Push trolley.
  • Marking: CE-marked
    Select a row from the table below, then click the add to quote button
    Part Code Code WLL
    kg
    Model Motor
    kW
    Max. lifting height
    m
    Load Chain dia x pitch
    mm
    Chain falls Lifting speed
    m/min.
    Duty rating % ED Construction height
    mm
    Weight
    kg
    0511001-3 8717365098758 0,13 BETA-125KG-3M 0,18 10 3 x 9 1 6,5 25 280 7,25
    0511001-4 8717365118142 0,13 BETA-125KG-4M 0,18 10 3 x 9 1 6,5 25 280 8,5
    0511001-5 8717365118159 0,13 BETA-125KG-5M 0,18 10 3 x 9 1 6,5 25 280 9,75
    0511001-6 8717365118166 0,13 BETA-125KG-6M 0,18 10 3 x 9 1 6,5 25 280 11
    0511001-7 8717365118173 0,13 BETA-125KG-7M 0,18 10 3 x 9 1 6,5 25 280 12,25
    0511001-8 8717365118180 0,13 BETA-125KG-8M 0,18 10 3 x 9 1 6,5 25 280 13,5
    0511001-9 8717365118197 0,13 BETA-125KG-9M 0,18 10 3 x 9 1 6,5 25 280 14,75
    0511001-10 8717365118203 0,13 BETA-125KG-10M 0,18 10 3 x 9 1 6,5 25 280 16
    0511003-3 8717365098765 0,2 BETA-200KG-3M 0,18 10 3 x 9 1 3,8 25 280 7,25
    0511003-4 8717365118210 0,2 BETA-200KG-4M 0,18 10 3 x 9 1 3,8 25 280 8,5
    0511003-5 8717365118227 0,2 BETA-200KG-5M 0,18 10 3 x 9 1 3,8 25 280 9,75
    0511003-6 8717365118234 0,2 BETA-200KG-6M 0,18 10 3 x 9 1 3,8 25 280 11
    0511003-7 8717365118241 0,2 BETA-200KG-7M 0,18 10 3 x 9 1 3,8 25 280 12,25
    0511003-8 8717365118258 0,2 BETA-200KG-8M 0,18 10 3 x 9 1 3,8 25 280 13,5
    0511003-9 8717365118265 0,2 BETA-200KG-9M 0,18 10 3 x 9 1 3,8 25 280 14,75
    0511003-10 8717365118272 0,2 BETA-200KG-10M 0,18 10 3 x 9 1 3,8 25 280 16
