Properties

  • Adjustable loading forks.
  • Height adjustment.
  • Minimum load 25% of total safe capacity.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Fork dimension
mm
diameter eye inside
mm
B
mm
D
mm
H
mm
H1
mm
Weight
3259010 8717365020858 1 RPHA-1 1000 x 100 z 30 100 x 80 350 - 900 100 x 30 1300-2000 1655-2355 140
3259020 8717365020865 2 RPHA-2 1000 x 100 x 40 100 x 80 400 - 900 120 x 40 1300-2000 1655-2355 220
3259031 8717365020872 3 RPHA-3L 1000 x 120 x 50 120 x 100 450 - 900 120 x 50 1300-2000 1720-2420 280
3259050 8717365020889 5 RPHA-5 1000 x 150 x 60 136 x 120 530 - 1000 150 x 60 1300-2000 1850-2650 380
