COBK beam lifting clamp is made with a safety mechanism that makes sure that the beam cannot slide out of the clamp during transport.
The clamp is locked in open and closed position.

Application

  • For horizontal lifting, transportation and stacking of steel (H) beams, profiles and structures.
  • Jaw openings available from: 3 to 20 mm.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
  • Safety factor: 5
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Jaw opening
mm
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
H
mm
Y
mm
Weight
3313022 8717365259081 2 COBK-2.0 3-20 3-20 285 157 295 64 155 67 65 17 19
