The REMA LK has proven to be a reliable and safe electric chain hoist under the most difficult conditions and circumstances.

Properties

  • Very high lifting capacities for electric chain hoists up to 12.5 tonnes.
  • Patented braking system that holds the load at any desired height.
  • Slip clutch against overload of the hoist.
  • Limit highest and lowest hook position by means of limit switches.
  • High duty cycle combined with high lifting speeds.
  • Galvanized load chain, class DAT (Grade 8).

Standard delivery

  • 3 m lifting height (maximum distance between suspension link and lower hook).
  • 1.8 m control cable with push button.
  • Push button switch box 24VAC control voltage.
  • Equipped with limit switches highest and lowest hook position.
  • 1 m power cable.
  • Chain bag.
  • 2-hole suspension plate.
  • Trolley not included.

Option

  • Any other hoisting and operating height is also possible.
  • Larger chain bag.
  • Deviating voltages and frequencies.
  • Radio control.
  • Hook suspension.
  • Electric trolley.
  • Capacities above 12.5 tons to 25 tons on request.
  • Marking: According to standard, CE-marked
  • Standard: EN 818-7, EN 12100, EN 14492
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Model Motor
kW
Max. lifting height
m
Load Chain dia x pitch
mm
Chain fall Lifting speed
m/min.
Duty group of hoist FEM 9.511 Duty rate [%] / Starts per hour S/h Trolley type kg Standard chain bag for lifting height
m
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
G2
mm
H
mm
H2
mm
J
mm
L
mm
M
mm
N
mm
Weight
kg
0803037 8717365001994 5 LK13/5000 6.0/1.3 16 16 x 45 1 5.6/1.4 1Am 60/40 - 180 12 500 10 567 183 434 500 66 140-310 823 901 957 1 036 42 700 256 430 242
0803039 8717365002007 6,3 LK13/6300 6.4/1.6 16 16 x 45 1 5.6/1.4 1Bm 60/40 - 150 12 500 10 567 183 434 500 66 140-310 823 901 957 1 036 42 700 256 430 242
0803041 8717365002014 8 LK13/8000 6.0/1.3 8 16 x 45 2 2.8/.07 2m 60/40 - 240 12 500 5 567 183 434 500 66 140-310 916 994 957 1 036 52 700 256 430 260
0803043 8717365002021 10 LK13/10000 6.0/1.3 8 16 x 45 2 2.8/0.7 1Am 60/40 - 180 12 500 5 567 183 434 500 66 140-310 916 994 957 1 036 52 700 256 430 260
0803045 8717365002038 12,5 LK13/12500 6.4/1.6 8 16 x 45 2 2.8/0.7 1Bm 60/40 - 150 12 500 5 567 183 434 500 66 140-310 916 994 957 1 036 52 700 256 430 260
