Mechanical properties

  • Aluminum housing.
  • Alloy steel pulling unit.
  • Test load 2 x WLL (without losing accuracy).
  • Safety factor 5 x WLL.
  • International Protection Rating / Ingress Protection: IP65 (EN60529).

Electrical specifications

  • Alkaline battery (3 x AA type).
  • Battery operating time about 180 hours.

Electronic specifications

  • Operating temperature range between -5 ° C to + 55 ° C.
  • Accuracy up to approx. 0.1% of the reading value.
  • Battery indicator.

Standard delivery

  • Bow shackles (3,2T and 6,3T).
  • Remote control to tare.

Option

  • Bow shackle from 10T.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155, EN 13889
  • Note: Includes plastic case, manual and calibration report.
  • Safety factor: 5
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Shackle Resolution
kg
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
Weight
1514005 8717365110986 3,2 DSD05T-3.2T 3,25t in. 1 199 69 130 25 269 20 4,7
1514007 8717365110993 6,3 DSD05T-6.3T 6,5t in. 2 213 69 144 35 348 26 7
1514009 8717365112003 10 DSD05T-10.0T 12t ex. 5 265 100 181 50 455 36 9,6
