Mechanical properties

  • Aluminum housing.
  • Alloy steel pulling unit.
  • Test load 2 x WLL (without losing accuracy).
  • Safety factor 5 x WLL.
  • International Protection Rating / Ingress Protection: IP65 (EN60529).

Electrical specifications

  • Alkaline battery (3 x AA type).
  • Battery operating time about 180 hours.

Electronic specifications

  • Operating temperature range between -5° C to + 55° C.
  • Accuracy up to approx. 0.1% of the reading value.
  • Battery indicator.

Option

  • U-13 Unilock bow schackle (2635013).
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155, EN 13889
  • Note: Includes plastic case, manual and calibration report.
  • Safety factor: 5
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Shackle Resolution
kg
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
Weight
1514001 8717365111983 0,6 DSD05-0.6T U-13 ex. 0,2 170 16 21 - - - 2,3
1514003 8717365111990 1 DSD05-1.0T U-13 ex. 0,5 170 16 21 - - - 2,3
