Application

  • Specifically developed for safe lifting and transportation fluted plates of dams. These clamps must always be used in pairs.

Option

  • Schackle (3011011)
  • Marking: According to standard, CE-marked
  • Standard: EN 13155, EN 12100
  • Note: Always apply these clamps per pair.
  • Warning: WLL 3t is per pair
    Select a row from the table below, then click the add to quote button
    Part Code Code WLL
    ton
    Jaw width
    mm
    Model A
    mm
    B
    mm
    C
    mm
    D
    mm
    E
    mm
    F
    mm
    G
    mm
    Weight
    kg/pair
    3313023 8717365015298 3 0-20 CDK-3.0 185 80 140 15 25 115 40 7,6
