The REMA X-Line hand chain hoist is a robust and ergonomic hoist for intensive use.

Properties

  • Low operating force at full load.
  • Increased operational safety due to double pawl system.
  • Brake is provided with astbestos free friction discs.
  • Load chain wheel is made of wear-resistant alloy steel.
  • Top and bottom hook have safety latches.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • Galvanized load chain (Grade 8).
  • Galvanized hand chain.
  • Steel housing with orange colored powder coating.

Standard delivery

  • 3 meters lifting height (max. between top and bottom hook).
  • 2.5 meters operating height.

Option

  • Available in any other hoisting and operational heights.

Norm:

  • EN12100-1/2, EN13157, EN818-7
  • Marking: According to standard, CE-marked
  • Standard: EN 13157, EN 818-7
Select a row from the table below, then click the add to quote button
Part Code Code WLL
kg
Model Load Chain dia x pitch
mm
Hand Chain dia x pitch
mm
Chain fall Construction height
mm
Hand force max.
kg
A
mm
B
mm
C
mm
D
mm
H
mm
Weight
kg
0170000 8717365112416 0,25 X-CH025/250KG 4.0 x 12 5.0 x 23.7 1 260 23,5 108 106 20 30 260 6
0170001 8717365088506 0,5 X-CH05/500KG 5.0 x 15 5.0 x 23.7 1 280 24,9 130 128 22 34 280 9
0170003 8717365088513 1 X-CH10/1000KG 6.3 x 19 5.0 x 23.7 1 330 28,4 150 142 26 39 330 12
0170005 8717365088520 1,5 X-CH15/1500KG 7.1 x 21 5.0 x 23.7 1 360 30,8 170 158 29 42 360 16
0170007 8717365088537 2 X-CH20/2000KG 8.0 x 24 5.0 x 23.7 1 385 34,3 185 175 35 49 385 20
0170009 8717365088544 3 X-CH30/3000KG 7.1 x 21 5.0 x 23.7 2 510 34,3 220 158 37 50 510 24
0170011 8717365088551 5 X-CH50/5000KG 9.0 x 27 5.0 x 23.7 2 615 37,2 255 183 43 60 615 37
0170015 8717365088636 10 X-CH100/10000KG 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 68
