• Material: AISI 316
  • Marking: According to standard, CE-marked
  • Standard: EN 818-4
  • Safety factor: 4
  • Grade: 6
Select a row from the table below, then click the add to quote button
Part Code Code WLL Size Model P
mm
D
mm
E
mm
T
mm
H
mm
O
mm
W
mm
Weight
2686406 8717365176821 0,9 6/5 RCA06SF-6/5MM 90 8 21 13,5 21 23 72 0,25
2686408 8717365176838 1,6 8/7 RCA08SF-8/7MM 118 13 27 19,5 29 27 103 0,7
2686410 8717365177859 2,5 10 RCA10SF-10MM 140 15 37 27 33 39 120 1,35
2686413 8717365177866 4,25 13 RCA13SF-13MM 182 18 48 35 46 51 155 2,6
