For lifting and transportation of beams or as fixed suspension points.

Properties

  • Equipped with suspension eye.
  • Locking spindle by means of Allen screw for extra safety.
  • Easy assembly by spindle.
  • Suitable for IPE and INP bars.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
  • Safety factor: 4
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Jaw opening
mm
A max
mm
B min
mm
B max
mm
C
mm
D
mm
E
mm
F max
mm
F min
mm
G
mm
H
mm
K
mm
Weight
3317101 8717365114595 1 KSBO-1 80-245 270 183 370 94 4 218 100 154 18 28 43 4
3317102 8717365114601 2 KSBO-2 80-245 270 183 370 102 6 218 100 154 18 28 43 5
3317103 8717365114618 3 KSBO-3 90-330 355 243 500 132 8 276 148 219 40 43 60 10
3317105 8717365114625 5 KSBO-5 90-330 355 243 500 142 10 276 148 219 40 43 60 12
3317110 8717365114632 10 KSBO-10 90-340 364 269 521 180 12 301 165 239 47 62 91 18,5
