Properties

  • Easy operation.
  • Robust construction.
  • Hard chromed cylinder.
  • Braked steering wheels are rotatable through 360 °.
  • Rotating load hook (not under load).
  • Jack adjustable in 4 positions.
  • 125% proof burden.
  • Safety valve against overload.

Application

  • Suitable for euro pallets 800x1200mm.
  • Marking: According to standard, CE-marked
  • Standard: EN 14985, EN 12100
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model WLL P1
kg
WLL P2
kg
WLL P3
kg
WLL P4
kg
B1
mm
B2
mm
B3
mm
H
mm
H1
mm
H2
mm
H3
mm
H4
mm
H5
mm
L1
mm
L2
mm
L3
mm
Weight
4220011 8717365019500 0,5 GWKE-500 500 450 400 350 925 840 1 000 1 595 155 470 705 2 225 2 475 1 360 1 060 1 395 81
4220013 8717365019517 1 GWKE-1000 1 000 900 800 700 925 840 1 000 1 595 155 470 705 2 225 2 475 1 360 1 060 1 395 103
