Properties

  • Low forces thanks to the optimum transmission ratios.
  • Robust construction with large-size, stable foot plate.
  • Safety crank with foldable handle.
  • Type DMK standard model.
  • Type DMKR with ratchet crank.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13157, DIN-EN 7355
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Lifting height max
mm
Minimum height of fork
mm
Construction height
mm
Weight
1950015 8717365000317 1,5 DMK-1.5 350 70 725 12
1950016 8717365025815 1,5 DMKR-1.5 350 70 725 15
1950030 8717365000324 3 DMK-3.0 350 75 725 20
1950031 8717365025822 3 DMKR-3 350 75 725 23
1950050 8717365000331 5 DMK-5.0 300 75 725 29
1950051 8717365025839 5 DMKR-5 300 70 725 27
1950100 8717365000348 10 DMK-10.0 300 85 800 42
