WF screw clamps are the lightest clamps with the highest capacity by means of a double round pivot. Special high-quality Alloy steel housing provides a safety factor of 8. The clamp is equipped with a double locking mechanism with movable pivots that guarantees increased clamping capacity.

Properties

  • Double round pivot locking, resulting in stronger clamping force and safe operation.
  • Because of the two attachment holes it is possible to carry out work in all directions.
  • This clamp can be used to hoist inclined loads such as I-beams.
  • Fine adjusting screw thread.
  • Preservation powder coating.
  • The pivots and the screw are specially treated to prevent rusting.

Application

  • Hoisting and transport work: Steel material, including H-beams, I-beams, steel plates, tubes, angle profiles and steel posts, as well as steel beams, pillars, welded objects and other workpieces.
  • Lowering workpieces easly with any hoisting equipment.
  • Dragging steel plates to arrange them on the ground.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Minimum load
kg
Jaw opening
mm
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
H
mm
I
mm
J
mm
K
mm
L
mm
M
mm
N
mm
O
mm
P
mm
Q
mm
R
mm
Weight
3316001 8717365030727 0,5 WF-0.5 50 3-28 41 32 30,5 21 33 108 138 34 42 10 25 24,5 12 16 120 10 26 21 1,5
3316003 8717365030734 1 WF-1.0 100 3-40 53,5 38 42,5 25 40 132 172 34 50 10 30 29,5 16 20 120 12 34 26 2,9
3316005 8717365030741 2 WF-2.0 200 3-45 60 45 47,5 31 41 157 202 34 62 10 34 33 22 28 150 12 36 29 4,9
3316007 8717365030758 3 WF-3.0 300 6-49 65,5 52 51,5 35 44 170 230 34 70 10 35 40,5 28 33 160 12 40 36 7,2
3316009 8717365030765 5 WF-5.0 500 9-53 71 57 55,5 38 46 187 248 34 75 10 40 45 38 40 180 12 41 36 10
