Properties

  • Suitable for steel barrels of 210 liter capacity and max diameter of 570 mm.
  • Clamping force is provided by the dead weight of the full barrel.
  • Can be easily mounted by simply pushing the clamp onto the fork.
  • Robust steel construction.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
    Select a row from the table below, then click the add to quote button
    Part Code Code WLL
    ton
    Model Jaw opening
    mm
    Weight
    kg
    4252005 8717365019814 0,68 DTS-10 572 36
