Developed for lifting steel beams or as a semi permanent hoist eye.

Properties:

  • Beam clamp equipped with spindle for quick and easy mounting on a beam.
  • Safety factor of at least 5 x WLL.
  • Each clamp is 2 x WLL test.
  • Marking: According to standard, CE-marked
  • Standard: EN 12100, EN 13155
  • Safety factor: 5
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Jaw opening
mm
A
mm
B
mm
D
mm
Weight
3367001 8717365015908 1 CSVW-1.0 75 - 190 135 - 250 170 120 3
3367002 8717365015915 2 CSVW-2.0 75 - 190 135 - 250 170 120 4
3367003 8717365015922 3 CSVW-3.0 75 - 190 135 - 250 170 120 4
3367005 8717365015946 5 CSVW-5.0 150 - 300 230 - 380 325 180 12
