The REMA Alpha 400 V electric chain hoists are compact and very low in weight (aluminium housing). Can be used in many situations due to high duty cycle in combination with a high lifting speed.

Properties

  • Slip clutch against overload.
  • Self-locking brake that holds the load at any desired height.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • Galvanized load chain, class DAT (Grade 8).

Technical specification:

  • Insulation class E.
  • FEM 9.511 motor: 2m.
  • Power supply 400VAC.
  • Protection class IP54.
  • Control power supply 24VAC.

Standard delivery

  • 3 m lifting height (maximum distance between top and bottom hook).
  • 1.8 m control cable, direct control.
  • Limit switches top and lowest hook positions.
  • 24V pendant control station.
  • 4 m power cable.
  • Plastic chain bucket up to 6 m chain, from 6 m chain plastic bag.
  • Trolley not included.

Option

  • Other hoisting and operating height is also possible.
  • Larger chain container > 3 m.
  • Push trolley.
  • Marking: CE-marked
    Select a row from the table below, then click the add to quote button
    Part Code Code WLL
    ton
    Model Motor
    kW
    Max. lifting height
    m
    Load Chain dia x pitch
    mm
    Chain falls Lifting speed
    m/min.
    Duty rating % ED Construction height
    mm
    Weight
    kg
    0514001-3 8717365087912 0,15 ALC/150KG/3M 400V 0,55 30 4.0 x 12 1 9 40 325 17
    0514001-4 8717365087929 0,15 ALC/150KG/4M 400V 0,55 30 4.0 x 12 1 9 40 325 18
    0514001-10 8717365087981 0,15 ALC/150KG/10M 400V 0,55 30 4.0 x 12 1 9 40 325 20
    0514001-5 8717365087936 0,15 ALC/150KG/5M 400V 0,55 30 4.0 x 12 1 9 40 325 20
    0514001-6 8717365087943 0,15 ALC/150KG/6M 400V 0,55 30 4.0 x 12 1 9 40 325 22
    0514001-7 8717365087950 0,15 ALC/150KG/7M 400V 0,55 30 4.0 x 12 1 9 40 325 24
    0514001-8 8717365087967 0,15 ALC/150KG/8M 400V 0,55 30 4.0 x 12 1 9 40 325 26
    0514001-9 8717365087974 0,15 ALC/150KG/9M 400V 0,55 30 4.0 x 12 1 9 40 325 28
    0514003-3 8717365087998 0,25 ALC/250KG/3M 400V 0,55 30 4.0 x 12 1 9 40 325 18
    0514003-4 8717365088001 0,25 ALC/250KG/4M 400V 0,55 30 4.0 x 12 1 9 40 325 20
    0514003-5 8717365088018 0,25 ALC/250KG/5M 400V 0,55 30 4.0 x 12 1 9 40 325 22
    0514003-6 8717365088025 0,25 ALC/250KG/6M 400V 0,55 30 4.0 x 12 1 9 40 325 24
    0514003-7 8717365088032 0,25 ALC/250KG/7M 400V 0,55 30 4.0 x 12 1 9 40 325 26
    0514003-8 8717365088049 0,25 ALC/250KG/8M 400V 0,55 30 4.0 x 12 1 9 40 325 28
    0514003-10 8717365088063 0,25 ALC/250KG/10M 400V 0,55 30 4.0 x 12 1 9 40 325 32
    0514003-9 8717365088056 0,25 ALC/250KG/9M 400V 0,55 30 4.0 x 12 1 9 40 325 42
    0514005-3 8717365088070 0,5 ALC/500KG/3M 400V 0,55 15 4.0 x 12 2 4,5 40 415 18
    0514005-4 8717365088087 0,5 ALC/500KG/4M 400V 0,55 15 4.0 x 12 2 4,5 40 415 20
    0514005-5 8717365088094 0,5 ALC/500KG/5M 400V 0,55 15 4.0 x 12 2 4,5 40 415 22
    0514005-6 8717365088100 0,5 ALC/500KG/6M 400V 0,55 15 4.0 x 12 2 4,5 40 415 24
    0514005-7 8717365088117 0,5 ALC/500KG/7M 400V 0,55 15 4.0 x 12 2 4,5 40 415 26
    0514005-10 8717365088148 0,5 ALC/500KG/10M 400V 0,55 15 4.0 x 12 2 4,5 40 415 32
