Properties

  • Equipped with a thread spindle for easy attachment, providing a powerful clamping force on the workpiece
  • Lightweight design for easy handling.
  • Maintenance-friendly, easy to exchange parts which are available upon request.

Application

  • For use as a (temporary) lifting point in spaces with HP- (bulb) profiles, like sectional ship parts and ship engine rooms.
  • Used for HP-100 to HP-240 (bulb) profiles.
  • Marking: According to standard, CE-marked
  • Standard: EN 13155, EN 12100
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Jaw opening
mm
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
Weight
3313018 8717365261794 1,5 CBS-1.5 HP100-240 180 75 150 16 45 75 40 3
3313019 8717365015274 3 CBS-3.0 HP100-240 205 75 150 16 45 75 80 6,5
