Properties

  • End fittings Grade 10.
  • Round sling coupling (WCL) for the safe and smooth connection of round slings with end fittings.
  • Indentification label.
  • Length round sling is 1 meter
  • Features: Option: Extra length round sling and protective cover on request.
  • Marking: According to standard, CE-marked
  • Standard: EN 1492-2, EN 1677-1
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Masterlink hook type Protection For connecting link For roundslings ton WLL 0-45°
t
WLL 45-60°
t
2592101 8717365020933 1 2SPR-1000KG-1M RML-86 REH-8 BS-50 WCL-8 S5-1.0 1,4 1
2592201 8717365020940 2 2SPR-2000KG-1M RML-86 REH-8 BS-60 WCL-8 S5-2.0 2,8 2
2592301 8717365020957 3 2SPR-3000KG-1M RML108 REH-10 BS-60 WCL-10 S5-3.0 4,2 3
2592401 8717365020964 4 2SPR-4000KG-1M RML-1310 REH-13 BS-75 WCL-13 S5-4.0 5,6 4
2592501 8717365020971 5 2SPR-5000KG-1M RML-1310 REH-13 BS-75 WCL-13 S5-5.0 7 5
