Properties

  • Suitable both for manual and mechanical drive.
  • Maintenance-free design.
  • Sheave dimensions according to RZ-0,5 to RZ-5,0.
  • Steel stand.
  • A cable guide is provided on the support.
  • Self-lubricating bearings.
  • Marking: According to standard, CE-marked
  • Standard: EN 13157, EN 12100
Select a row from the table below, then click the add to quote button
Part Code Code WLL Model Cable Diameter
mm
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
H
mm
I
mm
Weight
3064001 8717365025624 0,5 RBZ-0.5 5 - 6 150 125 82 115 55 88 15 92 11,5 3,25
3064003 8717365025631 1 RBZ-1.0 8 - 10 235 200 108 187 70 150 20 138 18 10,6
3064005 8717365025648 2 RBZ-2.0 12 - 14 325 280 143 260 95 212 25 190 23 31
3064007 8717365025655 3 RBZ-3.0 16 - 18 400 340 188 330 130 242 30 236 28 52
