The REMA Alpha 230 V electric chain hoists are compact and have a very low weight (aluminum housing). Popular hoist due to the high duty cycle in combination with a high lifting speed.

Properties

  • Slip clutch against overload.
  • Self-locking brake that holds the load at any desired height.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • Galvanized load chain, class DAT (Grade 8).

Type description:

  • ALH = 1 speed lifting.
  • ALHB = 2 speed lifting.
  • ALHV = Variable speed.

Technical specification:

  • Insulation class B.
  • FEM 9.511 motor: 1Am.
  • Power supply 230VAC.
  • Protection class IP54
  • Control power supply 230VAC direct control.

Standard delivery

  • 3 m lifting height (maximum distance between top and bottom hook).
  • 1.8 m control cable, direct control.
  • 4 m power cable.
  • Plastic chain bucket up to 6 m chain, from 6 m chain plastic bag.
  • Trolley not included.

Option

  • Other hoisting and operating height is also possible.
  • Larger chain container > 3 m.
  • Radio remote control.
  • Push trolley.
  • Marking: According to standard, CE-marked
  • Standard: EN 818-7, EN 14492, EN 12100
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Model Motor
kW
Max. lifting height
m
Load Chain dia x pitch
mm
Chain fall Lifting speed
m/min.
Duty rating % ED Construction height
mm
Weight
kg
0513005 8717365001666 0,1 ALH01/100 0,3 30 4.0 x 12 1 13 30 325 15
0513015 8717365001703 0,1 ALHB010/100 0,3 30 4.0 x 12 1 13.0/4.0 30 325 15
0513101 8717365258503 0,1 ALHV01/100 0,3 30 4.0 x 12 1 1~13.0 30 325 15
0513007 8717365001673 0,16 ALH016/160 0,6 30 4.0 x 12 1 15 30 325 17
0513017 8717365001703 0,16 ALHB016/160 0,6 30 4.0 x 12 1 15.0/5.0 30 325 17
0513103 8717365258510 0,16 ALHB016/160 0,6 30 4.0 x 12 1 1~15 30 325 17
0513009 8717365001680 0,25 ALH025/250 0,6 30 4.0 x 12 11 10 30 325 17
0513019 8717365001727 0,25 ALHB025/250 0,6 30 4.0 x 12 1 10.0/4.0 30 325 17
0513011 8717365001697 0,5 ALH05/500 0,6 15 4.0 x 12 2 5 30 415 20
0513021 8717365001734 0,5 ALHB050/500 0,6 15 4.0 x 12 2 5.0/2.0 30 415 20
